Black Berkey Purification Element Filters
Please note: 1 Single Black Berkey element is 1 single filter, to purchase a pair (2) select the quantity 2
*The Black Berkey® Purification Elements are made and assembled in the USA
- Black Berkey® Purification Elements are the leader in gravity-fed water purification, backed by independent testing
- The Black Berkey® Purification Element formulation has been tested by State and EPA accredited laboratories to exceed NSF/ANSI Standard 53
- Includes: Two 9″ Black Berkey® Purification Elements with 2 washers, 2 wing nuts, and 1 priming button
- Installs in the upper chamber of any Berkey system. Elements can also be used to upgrade most other gravity-fed water filter systems
- Sold as a set of 2 elements
- Durability: Each Black Berkey® Element is designed to purify approximately 3,000 gallons of water before needing replacement; 2 elements in a Berkey system will purify approximately 6,000 gallons of water before replacement is recommended
- Re-cleanable and self-sterilizing during the life of the element
- Elements come with a 2-year, pro-rated warranty
Set of 2 replacement filters. Will fit the following Berkey systems: Travel Berkey, Big Berkey, Royal Berkey, Imperial Berkey, Crown Berkey, Berkey Light. Black Berkey Purification Elements are more powerful than any other gravity filter element currently available. In fact, we tested the Black Berkey purification elements with more than 10,000 times the concentration of pathogens per liter than is required by standard test protocol. This concentration of pathogens is so great that the post filtered water should be expected to contain 100,000 or more pathogens per liter (99.99% reduction – the requirement for pathogenic removal). Incredibly the purification elements removed 100%. Absolutely no pathogens were cultured from the effluent or were able to be detected, even under an electron microscope, setting a new standard in water purification. Black Berkey purification elements are so powerful, they can remove red food coloring from water without removing the beneficial minerals your body needs. Virtually no other filtration element can duplicate this performance. The powerful Black Berkey purification elements also remove or reduce viruses, pathogenic cysts, parasites, harmful or unwanted chemicals such as herbicides and pesticides, VOCs, detergents, organic solvents, trihalomethanes, cloudiness, silt, sediment, nitrates, nitrites, heavy metals, foul tastes and odors, yet they leave in the healthful and beneficial minerals that your body needs.
The Black Berkey Filter Elements have been tested and confirmed to remove or greatly reduce the contaminants listed below:
Viruses: 99.999% reduction
MS2 – Fr Coliphage
*Exceeds purification standards
Pathogenic Bacteria, Parasites, and Cysts: Removed to non-detectable levels – 100% reduction
E. coli, Klebsiella terrigena, Pseudomonas aeruginosa, Giardia, Cryptosporidium
*Exceeds purification standards
Trihalomethanes: Removed to below detectable limits – 99.99999% reduction
Bromodichloromethane, Bromofore, Chloroform, Dibromochloromethane
Inorganic Minerals: Removed to non-detectable levels – 99.9999999% reduction
Heavy Metals: Greater than 95% reduction
Lead, Mercury, Aluminum, Cadmium, Chromium, Copper
Volatile Organic Compounds: Removed to below detectable limits – 99.9999999% reduction
Alachlor, Atrazine, Benzene, Carbofuran, Carbon Tetrachloride,
Chlorine, Chlorobenzene, Chloroform, 2 4-D, DBCP,
p-Dichlorobenzene, o-Dichlorobenzene, 1 1-Dichloroethane
1 2-Dichlorpethane, 1 1-Dichloroethylene, Cis-1 2-Dichloroethyiene
Trans-1 2-Dichloroethylene, 1 2-Dichloropropane
Cis-l 3-Dichloropropylene, Dinoseb, Endrin, Ethylbenzene
Ethylene Dibromide (EDB), Heptachlor, Heptachlor Epoxide
Hexachlorobutodlene, Hexachloro-, Cyclopentadlene, Lindane
Methoxychlor, MTBE, Pentachlorophenol, Simazine, Styrene
1,1,2,2-Tetrachloroethane, Tetrachloroethylene, Toluene
2,4,5-TP (Silvex), 1 2 4-trichlorobenzene, 1 1 1-trichloroethane
1 1 2-trichloroethane, Trichloroethylene, o-Xylene, m-Xylene
How do I prime the Black Berkey filters correctly?
Turn the tap on slightly so that there is a small stream of water. If the stream is too hard you’ll have water squirting all over the place and if it’s too slight then there won’t be enough water pressure. You must create a seal between the tan washer and your tap so that the water from your tap is forced to go through the filters, thus pushing out the air in the filters. See the second photo below: Priming a Black Berkey filter element, here you see how to create the seal. Then you should see your filters “sweating” water from bottom to top, it takes about 30 seconds to a minute.
I just bought a Berkey water purification system but it’s hardly filtering any water at all. Am I doing something wrong?
The problem you are experiencing is probably due to high water tension, which is preventing the air from being purged from the micro pores of the new purification elements. Water tension varies from country to country and from area to area and can also change from season to season. The higher the water tension the more difficult it is for the water, using gravity pressure, to force the air from the micro-pores of the new element. Included with your Black Berkey filters is a tan priming washer and instructions for it’s use. Please remove and prime your purification elements, reinstall them and that should correct the problem.
How do I prime the Black Berkey Purification Elements, in the field, when water pressure is unavailable?
There are two methods to prime filters where no water pressure is available. You can either follow the instructions below or purchase a Berkey primer which makes priming in the field much easier.
The micro pores on the Black Berkey purification elements are extremely small, in fact they are small enough to filter red food coloring out of water. The benefit from having such extremely small pores is greater efficiency at removing pathogenic bacteria and other contaminates. The downside is that too much water tension can require that the purification elements be primed before they will flow properly. When you receive the purification elements, they are dry and air is trapped within the tiny micro fine pores. In certain parts of the world, water has more water tension than in other places and this can change from season to season. The higher the water tension, the more difficult it is for the water to force the air out of the micro fine pores using gravity alone. The pores that have air trapped within them do not allow water to pass through and therefore become an inaccessible passage for the water. This then can cause the system to either filter very slowly or not at all.
Before traveling to the field or using the system in an area without water pressure, we recommend that the purification elements be primed using the priming button method. If water pressure is not available to use the priming button method, the elements can be field primed approximately 50-75% by using the below method. In other words by using this method, the elements will not purify as fast as they will by using the priming button method however they will run significantly faster than if the elements have not been primed at all. The field priming method is as follows:
Step 1: Fill the lower chamber with water, then place the purification elements into the water in the lower chamber, upside down with the stems facing upward. Put a ceramic coffee cup (or something else that will hold them under the water) on top of each purification element stem to force the element down under the water.
Or, install the elements upside down in the upper chamber so that the elements are on the exterior of the bottom side of the upper chamber facing downward. Then place the upper chamber onto the lower chamber so that the filters are forced into the water within the lower chamber.
Let the purification elements soak in the water for 30 to 60 minutes until they fill up with water. NOTE: Make sure that the opening in the stems of the purification elements are not underwater as the water must be forced through the pores of the element and not allowed to enter the element through the hole in the stem.
Step 2: When the inside of the purification elements are full of water they will be significantly heavier. Next, assemble the purification elements into the upper chamber while keeping the stems of the elements facing upward. It is important to keep as much water on the inside of the purification elements as is possible. Next, fill the upper chamber with water as quickly as possible. Hint: the fastest way to fill the upper chamber is to pour the water from the lower chamber into the upper chamber. Then place the upper chamber onto the lower chamber.
When the purification elements have water within the bore (inside core), more force is generated to draw water through the purification elements. This is because the water that drips out of the purification element also hydraulically pulls new water into the element as it begins to work like a siphon. Thus, in addition to the “Push” of gravity, there is also a hydraulic “pull” and this drastically improves the ability of the water to force the air from the micro pores. The above method is less efficient than priming the purification elements with the priming button but should be about 50-75% effective in clearing the blocked micro pores.
Let the water from the first purification cycle that is collected in the lower chamber run to waste. Next, refill the upper chamber with water. Your Black Berkey elements are now FIELD primed and your Berkey system is ready for use.
Note: If the water used to field prime the elements is from a contaminated or suspect source, if possible use a container other than the lower chamber to immerse the elements. If this is not possible then use the water that collects in the lower chamber from the first purification cycle to make a soapy dishwater. Then wash thoroughly the inside of the lower chamber and discard the soapy water. Next, purify more water and use it to rinse any remaining soap from the lower chamber. Your Berkey system is now ready for use.
- Failure to remove the Black Berkey® Purification Elements from the system prior to transporting or moving the system, resulting in broken stems.
- The stems breaking due to not carefully installing them to the PF-2 Filters or while cleaning the elements. **Please install/clean/use the black filters with care & ease. If the stems break due to carelessness they cannot be fixed, a new pair of filters will have to be purchased at your own cost.
Can I use the Berkey® system with softened water?
The Black Berkey® purification elements are designed to remove heavy metals, but will not remove mineral salts, which are added by a water softener. The salt used to soften water will not be extracted by the Black Berkey® element. You can use one of our purification systems on a regular basis by bypassing your water softener to get your drinking water. Most water softeners have a bypass valve or way to get water before it passes through your softener. Therefore, we highly recommend that you obtain pre-softened water directly from the source rather than run softened water through your Black Berkey® Elements.
